512 channels DMX controller
Voltage: AC220V, 50-60Hz;
DMX512 standard. 512 DMA control channels;
Two independent output drive ports with isolation, capable of withstanding 1500VDC electrical shocks. Independent plug-in structure, easy to replace;
Can control 32x16 channel computer lights;
Large screen LCD display screen with backlight, used to display various operating parameters;
16 channel push rods, 1 speed control push rod;
A storage capacity of 1600 LED program steps. 48 light walking programs, with a maximum of 100 steps per program. Each step speed and gradient parameter are set independently. Optional music synchronization or manual speed control;
With the cooperation of the light speed push rod, the time range of program steps can be from 0.03s to 180s;
48 computer light scenes that can be directly accessed;
Can run 4 lighting programs and 48 scenes simultaneously, and can manually run 32 computer lights at the same time (lighting), with channel release function for manual operation (lighting);
The X/Y of different types of computer lights can be controlled by a data wheel or by a pusher;
16 bit computer light X/Y control accuracy;
15 environment keys for quick access to different scenes, lighting, and manual operation combinations;
The music trigger signal source can be taken from the audio line input or the built-in microphone pickup;
Easy to learn and use, with higher operational efficiency;
◎ Shutdown data saving;
Equipped with a high-performance green switching power supply, it has extremely low power harmonic distortion and a wide voltage range, meeting global power requirements (90V-240V).
◎ Size: 565 ×400 × 175mm;
◎ Gross weight: 8kg.
